HUANGFU Xuerui, LI Yi, HU Rijun, ZHU Longhai, LIU Bo, YIN Yanjun. TEMPORAL AND SPATIAL VARIATION OF SUSPENDED SEDIMENT CONCENTRATION IN THE NEARSHORE WATERS OF WESTERN YANTAI AND ITS TRANSPORT CHARACTERISTICS IN WINTER[J]. Marine Geology Frontiers, 2020, 36(5): 22-33. DOI: 10.16028/j.1009-2722.2019.107
Citation: HUANGFU Xuerui, LI Yi, HU Rijun, ZHU Longhai, LIU Bo, YIN Yanjun. TEMPORAL AND SPATIAL VARIATION OF SUSPENDED SEDIMENT CONCENTRATION IN THE NEARSHORE WATERS OF WESTERN YANTAI AND ITS TRANSPORT CHARACTERISTICS IN WINTER[J]. Marine Geology Frontiers, 2020, 36(5): 22-33. DOI: 10.16028/j.1009-2722.2019.107
shu

TEMPORAL AND SPATIAL VARIATION OF SUSPENDED SEDIMENT CONCENTRATION IN THE NEARSHORE WATERS OF WESTERN YANTAI AND ITS TRANSPORT CHARACTERISTICS IN WINTER

  • 1.

    College of Marine Geosciences, Ocean University of China, Qingdao 266100, China

  • 2.

    Huaneng Xiapu Nuclear Power Co., Ltd., Ningde 352000, Fujian Province, China

  • 3.

    Key Laboratory of Submarine Geosciences and Prospecting Techniques, Ministry of Education, Ocean University of China, Qingdao 266100, China

More Information
  • Received Date: April 24, 2019
    Graphical Abstract
    • Abstract
  • Based on the simultaneous observation of currents and suspended matters in spring and neap tides at six stations in the coastal waters of Yantai Port in December 2017, this paper studied the temporal and spatial variation in suspended sediment concentrations. The transport flux of suspended matter was calculated, and the transport mechanism of suspended sediment under tidal currents discussed. The results show that the suspended sediment content in the spring tide is greater than that in the neap tide; and the concentration of suspended matter at each station has 2~4 peaks during the spring tide period, whereas that in the neap tide is more complicated and lack of regularity. The change in suspended sediment generally lags behind the flow rate change for 1~2 hours. From the view of plane distribution, the concentration of suspended sediment at different stations in the study period is quite different, and the difference in neap tide period is rather small. In the vertical direction, however, the suspended sediment content in each layer of the spring and neap tides has little change, and the stratification phenomenon is not obvious. The advection transport of the water in the study area dominates the suspended sediment transport, while the vertical net circulation plays a supporting role, and the contribution of other sediment transport modes is rather small. The net transport direction and residual flow of suspended sediment in the study area are roughly the same. The contribution of the vertical net circulation to the suspended sediment transport during the spring tide period is slightly larger than that during the neap tide period. The contribution of the advection transport in the neap tidal period to the suspended sediment transport is slightly greater than that during the spring tide period, and the influence of the fluctuation of spring and neap tides on the sediment transport is significant in the area.
    • FullText(HTML)
    • References (33)
  • [1]
    余佳.黄海悬浮体分布及季节性变化[D].青岛: 中国海洋大学, 2012.
    [2]
    杨作升, 王兆祥, 郑爱芬, 等.黄河口毗邻渤海陆架区悬浮体成分[J].青岛海洋大学学报, 1990, 20(1): 26-40.
    [3]
    乔璐璐.冬季大风事件下渤黄海环流及泥沙输运过程研究[D].青岛: 中国海洋大学, 2008.
    [4]
    Zhang J, Liu S M, Xu H, et al.Riverine sources and estuarine fates of particulate organic carbon from North China in late summer[J].Estuarine Coastal and Shelf Sciences, 1998, 46(3):439-448. DOI: 10.1006/ecss.1997.0277
    [5]
    Ma M, Feng Z, Guan C, et al.Pah and Pcb in sediments from the intertidal zone of the Bohai Sea and the Yellow Sea[J]. Marine Pollution Bulletin, 2001, 42 (2):132-136. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=e4012328789303378ca8d3a6df3f71c4
    [6]
    刘雪.基于遥感的中国东部海域悬浮泥沙季节变化研究[D].青岛: 中国海洋大学, 2014.
    [7]
    Bi N, Yang Z, Wang H, et al. Seasonal variation of suspended-sediment transport through the southern Bohai Strait[J]. Estuarine Coastal & Shelf Science, 2011, 93(3):239-247. https://www.sciencedirect.com/science/article/pii/S0272771411000886
    [8]
    江文胜, 苏健, 杨华, 等.渤海悬浮物浓度分布和水动力特征的关系[J].海洋学报, 2002(S1):212-217. http://www.cqvip.com/Main/Detail.aspx?id=1000451372
    [9]
    李爱超, 乔璐璐, 万修全, 等.渤海海峡悬浮体分布、通量及其季节变化[J].海洋与湖沼, 2016, 47(2):310-318. http://d.old.wanfangdata.com.cn/Periodical/hyyhz201602003
    [10]
    Zhang J, Huang W W, Martin J M. Trace metals distribution in Huanghe (Yellow River) estuarine sediments[J]. Estuarine Coastal and Shelf Science, 1988, 26(5):499-516. DOI: 10.1016/0272-7714(88)90003-0
    [11]
    秦蕴珊, 李凡, 郑铁民, 等.南黄海冬季海水中悬浮体的研究[J].海洋科学, 1986, 10(6):1-7. http://www.cnki.com.cn/Article/CJFDTotal-HYKX198606000.htm
    [12]
    鲍献文, 李真, 王勇智, 等.冬、夏季北黄海悬浮物分布特征[J].泥沙研究, 2010(2):48-56. http://d.old.wanfangdata.com.cn/Periodical/nsyj201002008
    [13]
    吴祥柏, 汪亚平, 潘少明.长江河口悬沙与盐分输运机制分析[J].海洋学研究, 2008, 26(4):8-19. DOI: 10.3969/j.issn.1001-909X.2008.04.002
    [14]
    杨林.废黄河口海域悬沙时空变化及输移特征[D].上海: 上海海洋大学, 2018.
    [15]
    张存勇.连云港近岸海域沉积物再悬浮及悬沙动力研究[D].青岛: 中国海洋大学, 2011.
    [16]
    杜家笔, 裴艳东, 高建华, 等.弱动力浅海中的悬沙输运机制:以天津港附近海域为例[J].海洋学报(中文版), 2012, 34(1):136-144. http://d.old.wanfangdata.com.cn/Periodical/hyxb201201017
    [17]
    林纪江, 胡日军, 朱龙海, 等.潮流作用下蓬莱近岸海域悬浮泥沙的时空分布及变化特征[J].海洋地质前沿, 2017, 33(12):13-23. http://hydt.cbpt.cnki.net/WKA/WebPublication/paperDigest.aspx?paperID=49c3c1d2-9280-4f19-8425-233e25efb493
    [18]
    张伟, 周连成, 吴建政, 等.渤海海峡南部海域表层沉积物分布特征及控制因素[J].海洋地质与第四纪地质, 2015, 35(5):19-28. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hydzydsjdz201505004
    [19]
    刘成, 胡日军, 朱龙海, 等.庙岛群岛海域沉积动力环境分区及沉积物输运趋势[J].海洋地质前沿, 2018, 34(8):26-35. http://hydt.cbpt.cnki.net/WKA/WebPublication/paperDigest.aspx?paperID=c31dc0d2-9adb-46a7-a6e9-274567b9be2c
    [20]
    李爱超, 乔璐璐, 万修全, 等.渤海海峡悬浮体分布、通量及其季节变化[J].海洋与湖沼, 2016, 47(2):310-318. http://d.old.wanfangdata.com.cn/Periodical/hyyhz201602003
    [21]
    Jiang S H, Hu R J, Feng X L, et al. Influence of the construction of the Yantai West Port on the dynamic sedimentary environment[J]. Marine Georesources & Geotechnology, 2017:1-9. DOI: 10.1080/1064119X.2017.1278809
    [22]
    董有强, 周锋.烟台港西港区规划锚地锚泊安全研究[J].中国水运, 2010(4):26-27. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgsy201004014
    [23]
    秦福寿, 王钺, 张国建, 等.烟台港西港区规划设计建设中关键技术问题回顾[J].港工技术, 2014(2):13-17. DOI: 10.3969/j.issn.1004-9592.2014.02.004
    [24]
    胡日军, 吴建政, 朱龙海, 等.东海舟山群岛海域表层沉积物运移特性[J].中国海洋大学学报(自然科学版), 2009, 39(3):495-500, 442. http://d.old.wanfangdata.com.cn/Periodical/qdhydxxb200903027
    [25]
    Yu Q, Wang Y P, Flemming B, et al. Tide-induced suspended sediment transport: Depth-averaged concentrations and horizontal residual fluxes[J]. Continental Shelf Research, 2012, 34:53-63. DOI: 10.1016/j.csr.2011.11.015
    [26]
    Xie D F, Gao S, Wang Z B, et al. Numerical modeling of tidal currents, sediment transport and morphological evolution in Hangzhou Bay, China[J]. International Journal of Sediment Research, 2013, 28(3):316-328. DOI: 10.1016/S1001-6279(13)60042-6
    [27]
    陈斌, 刘健, 高飞.莱州湾悬沙输运机制研究[J].水科学进展, 2015, 26(6):857-866. http://d.old.wanfangdata.com.cn/Periodical/skxjz201506012
    [28]
    陈斌, 高飞, 刘健.夏季浙江沿岸陆架区泥沙输运机制[J].海洋学报(中文版), 2017, 39(3):96-105. DOI: 10.3969/j.issn.0253-4193.2017.03.009
    [29]
    Ingram R G. Characteristics of the Great Whale River Plume[J]. Journal of Geophysical Research, 1981, 86(C3): 2017-2023. DOI: 10.1029/JC086iC03p02017
    [30]
    Uncles R J, Elliott R C A, Weston S A. Dispersion of salt and suspended sediment in a partly mixed estuary[J]. Estuaries and Coasts, 1985, 8(3):256-269. DOI: 10.2307/1351486
    [31]
    唐建华, 梁摇斌, 李若华.强潮河口悬浮泥沙浓度垂向结构分析——以杭州湾乍浦水域大潮期为例[J].水利水运工程学报, 2009(2):39-43. DOI: 10.3969/j.issn.1009-640X.2009.02.007
    [32]
    冷星, 朱龙海, 胡日军.山东半岛东部海域泥质区冬季悬浮泥沙时空变化及输运机制[J].中国海洋大学学报(自然科学版), 2019, 49(4):106-116. http://d.old.wanfangdata.com.cn/Periodical/qdhydxxb201904012
    [33]
    杨晓东, 姚炎明, 蒋国俊, 等.乐清湾悬沙输移机制分析[J].海洋通报, 2011, 30(1):53-59. DOI: 10.3969/j.issn.1001-6392.2011.01.009
